Start Up
                            On the right screen, click on the following icon in order to launch the program for EDS analysis.



                                               You must start up SEM application before starting EDS application. Don’t forget to switch
                            off the infrared camera.
                            Once you have launched the analysis station, Bias is applied to the EDS detector, the following
                            programs start and the respective icons appear on the task bar.
                                                                                                                      SEM monitor
                                                                                                                                               ssm dead time
                                         Analyzer Manager                                                                                                               Analyser manager
                                         SSM bias
                                         SSM dead time
                                         SSM probe tracking
                                         SEM monitor

                                                                                                                        ssm probe tracking          ssm bias

                            The basic windows of analysis open after the double click on Analysis station.



                                                         Define acquisition conditions
                  SEM condition: Accelerating voltage: 15kV, current: 20 µA, probe current 8 or 9, WD = 8mm

                  SSM rate meter:

                          SSM counting rate : 2000-7000 cps
                          Dead time 20 – 40 %

                                    Tip:  if dead time and/or counts are too low, increase PC gradually.

                              Press on Cond in the basic windows in order to define the acquisition conditions.


                  SPECTRUM ACQUISITION
                  Acquisition conditions must be defined as followed:
                          Pha mode : T3 (high resolution)
                          Preset : live time
                          Preset value : 100-300 secs



                           Tip : the number of counts for the time of acquisition must be round 200000. The more
                           counts you have, the better the precision of the quantitative analysis will be.

                    X-ray mapping

                               o  Pha mode : T3 (high resolution)
                               o  512*384
                               o  Preset number of scan
                               o  Dwell time : 0.1msec



                               o  Resolution : 1024x768
                               o  Preset : 1 Frame

                      Acquire image for analysis
       Before image acquisition via Analysis program, check and adjust focus and astigmatism in LM or SEM
       mode.


       Once image has been acquired, Acquire a spectrum.

                      Image and file disposition

       Samples and images-spectrum and mappings of samples can be arranged as in windows explorer.





                        Acquire a spectrum

       Acquisition conditions have already been defined; simply press on the Spc icon

       A new window with the spectrum acquisition of the defined area (area of the picture) will open.
